Line Bore Portable Boring Machine, 45-180MM(1.77-7.08inch) Drilling Diameter, Engineering Mechanical Connecting Rod Hole Drilling Tool with 4.9ft Boring Bar and Handle Control
$2,072.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by beatrizdujovneauthor.com
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$2,072.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by beatrizdujovneauthor.com
Free 30-day returns Details
Product details
| Management number | 221912284 | Release Date | 2026/05/04 | List Price | $828.80 | Model Number | 221912284 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【Parameters】 - The maximum processing hole diameter is Ф180mm(7.09inch); The minimum processing hole diameter: Ф45mm(1.77inch); Boring bar: 40*1500MM(1.57*59.06inch); The maximum processing travel: 380mm(14.96inch); The maximum feed depth: 2mm on one side (A3 steel); Surface roughness: Ra3.2; Deviation from circular form≤0.02mm; Rotate speed: 0-83RPM
- 【Motor and Handle Controller】 - The whole machine adopts 110V constant current motor with low speed and large torque, which can realize stable processing and superior performance. The motor controller is equipped with a dynamic delay braking program to avoid vibration during shutdown. After the machine is installed, the controller can be removed to control the machine and perform the drilling operation. The control cabinet is installed under the host, which is conducive to safe operation.
- 【4.9FT Boring Bar】 - The boring bar is made of high-strength alloy and structural steel, which has the characteristics of high hardness, high precision, high toughness and good wear resistance. The boring bar can be disassembled separately for convenient installation.
- 【Stepless Speed Regulation】 - Stepless speed regulation can be realized for feed processing. The feeding process can be set as required, and it will stop automatically after reaching the limit switch.
- 【Application】 - The drilling machine is a portable processing equipment developed for on-site service of construction machinery. It is mainly used for processing inner holes of small tubes and concentric cross holes. Widely used in excavators, cranes, loaders, cranes and other construction machinery.
